“The TECO Low Voltage range of motors is available in voltages up to 1kV, multiple enclosure types such as Totally Enclosed Fan Cooled (TEFC), Open Drip Proof (ODP). They are heavy duty cast iron construction Squirrel Cage Induction Rotor, Wound Rotor Induction Rotor, in both single and multi pole designs. All mounting forms are catered for such as Foot, Vertical Flange/ Face and Foot/Flange/Face mounting.

Features:
NEMA & IEC Frames
Vertical & Horizontal mountings
Large range of enclosures
Cast iron or steel plate frame
Type Code: AEEF
Low Voltage Squirrel Cage Motors
IEC Standard Size

Output 1/4 – 500 HP
Pole(Speed) 2 – 8
Voltage below 600v
Frequency (Hz) 50, 60
Frame Size 63 – 315M
Protection Enclosure IP 54”

Motor Rating(HP/kW)
0.5HP/0.37KW, 0.75HP/0.6KW, 1.5HP/1.1KW, 100HP/75kw, 10HP/7.5kw, 125HP/93kw, 150HP/112kw, 15HP/11kw, 175HP/130kw, 1HP/0.75KW, 200HP/149kw, 20HP/15kw, 250HP/187kw, 25HP/18kw, 2HP/1.5kw, 300HP/224kw, 30HP/22kw, 3HP/2.2kw, 40HP/30kw, 50HP/37kw, 5HP/3.7kw, 60HP/45kw, 7.5HP/5.5kw, 75HP/56kw

Voltage
220V, 380V, 440V

Pole/RPM
2Pole/3600RPM, 4Pole/1800RPM, 6Pole/1200RPM
